Introduction:
It is mainly used for cleaning or grading raw materials in flour making, feed, rice milling, chemical industry, oil pressing and other industries.
The three-motion combination of the screen body has good cleaning effect and stable and reliable performance.
| SPECS | TQLM80 | TQLM100 | TQLM125 | TQLM160 | TQLZ200X200 |
| Wheat processing capacity（t/h） | 4-6 | 6-8 | 8-12 | 10-15 | 15-20 |
| Screen width（cm） | 80 | 100 | 125 | 160 | 200 |
| Screen surface inclination（o） | Upper screen surface tilt 7o; Lower screen surface tilt 8o | ||||
| Revolving speed（r/min） | 300 | ||||
| Power（kw） | 0.55 | 0.55 | 0.75 | 1.1 | 1.5 |
| Vertical suction separator air volume（m3/min） | 60 | 80 | 90 | 100 | 120 |
| Weight（kg） | 750 | 800 | 850 | 900 | 1100 |
| Size（mm） | 2300×1210×1320 | 2300×1410×1320 | 2300×16610×1320 | 2300×1910×1320 | 2700×1950×1320 |
