Chaff Cutter Machine
Chaff Cutter Machine
  • Operating weight(kg)
    1020KG
  • Engine power(kW/rpm)
    15KW
  • Efficiency
    10T/H
  • Characteristic
  • Parameter
  • Case
  • Inquiry
Characteristic

Introduction:

Our newly designed chaff cutter machine or shredder is very easy to operate, which is mainly used to cut corn straw, wheat straw, rice straw, alfalfa and other kinds of crop straw and pasture, meanwhile, it also has grass silk kneading function, better for livestock's digestion and absorption. These processed materials is suitable for breeding cattle and sheep, deer, horse etc. The chaff cutter can also process cotton stalk, branches, bark, and so on, which can be used for straw generation ethanol, papermaking and artificial board etc.


Features:

1. It can process both dry and wet materials, no jamming in the machine, no tangling. It can also cut the feed into the thickness and length required by the user (Unique speed gear box structure, easy to adjust the length of the grass, the box is sealed and reliable, good lubrication).

2. The combination of chaff cutting and grass silk kneading is better for digestion and absorption for the livestock.

3. Work efficiently with advanced hay-conveying structure and hay-conveying rollers.

4. Transmission part of the configuration of self-aligning rolling bearings and universal joint, compact, flexible operation, easy disassembly.

5. Blade selection of high-quality steel, refined by a special process, super wear-resistant; high-strength bolts, which is safe and reliable.

6. Light and easy to move!

7. Safe and reliable machine designed to avoid accidents- Designed to have a knife safety guide device, to prevent eating knife accident!

8. Easy to take apart and install.

9. Multi choice engines – electric motors, diesel engines or tractors.

10. Steel structure for the machine body, and pure copper core electric motor, very durable!

11. Wider and thicker feeding inlet.

12. Strong air blowing function at the discharging outlet, blowing the cut chaff far away.

13. Considerate and direct service from factory. Free lifetime guidance in operation and maintenance. And 3-years warranty!


Chaff Cutter Machine(pic1)


Chaff Cutter Machine(pic2)

Parameter

Model

Capacity

(t/h)

Power

(kw)

Outline size

(mm)

Wooden case size

(mm)

Blade

quantity

(pcs)

Weight

(kg)

UG2.5

2-3

4

1250*1050*2000

1360*600*1220

6

220

UG4

4.5

5.5

1760*1535*2310

1560*740*1460

4

380

UG4A (With both

cutting and kneading

functions

4.5

5.5

1760*1535*2310

1560*740*1460

3

400

UG6

6

7.5

2250*1680*2860

1890*860*1740

3

540

UG6A (With both

cutting and kneading

functions

6

7.5

2250*1680*2860

1890*860*1740

3

560

UG9A(With both

cutting and kneading

functions)

9

11

2600*2200*3100

2200×950×1850

3

700

UG10

10

15

2630*2230*4127

2260*1000*2040

3

1020

UG10A(With both

cutting and kneading

functions)

10

15

2630*2230*4127

2260*1000*2040

3

1020
